Consumer Electronic Mini Woofer Speaker 4W 8 Ohm Car Speakers

Ask Lasest Price
Brand Name :	YUESEN
Model Number :	YD78-3A-8
Certification :	ISO2000, RoHS, REACH
Price :	$0.2/pcs~$1/pcs
Payment Terms :	T/T, Western Union
Supply Ability :	1-1.5million/month
Delivery Time :	2-4 weeks

Add to Cart

Product Details
Company Profile

Consumer Electronic Mini Woofer Speaker 4W 8 Ohm Car Speakers

YD78-3A-8 , consumer electronic Raw Frame Speakers 4W, 8ohm

We are a high-tech enterprise which integrates research, design, production and sales. Our products are widely used for TV, Mobile devices such as notebook, GPS, mobile DVD and so on.

General Specifications:

Dimensions	81×81mm
Rated Input Power	4W
Maximum Input Power	6W
Sound Pressure Level	88±3dB 1M/1W at 0.5, 0.6,0.8,1.0,1.5KHz
Impedance	8Ω±20% At400Hz 1V
Frequency Response	F0~15kHz(-10dB)
Operation	Must be normal. Program source 4W
Noise	Must be normal. Sine wave 5.65V
Heat Test	Shall be normal after test. 55±2℃ 16 hours
Magnet	Ф60XФ24X8 MATERIAL SIZE
Humidity Test	Shall be normal after test. 40±2℃ 90~95%RH 48 hours
Load Test	Shall be normal after test. Input Power: 4.0W White Noise Duration: 100 hours
Polarization	When a positive DC current is applied to the terminal marked(+), diaphragm shall move forward
Net Weight	235±12g
